Primary Welding Molding Thyristor Diode Module Big Power Inverse Parallel

Product Categories
Xi'an Noker Electric Co.,Ltd.
Contact Now

Primary Welding Molding Thyristor Diode Module Big Power Inverse Parallel

Brand Name : Noker

Model Number : JKT90-16

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Price : To be discussed later

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 set per month

Delivery Time : 10-15 work days

Packaging Details : Carton Packing

Electrical insulation : Chip and bottom electrical insulation

Power cycle : Good power cycle performance

Package : International Standard package

Voltage drop : Low on state voltage drop

Installation and maintain : Installation simple easy to maintain

Volume : Small volume light weight

Contact Now

Primary Welding Molding Big Power Inverse Parallel Low On State Voltage Drop Low Voltage Thyristor Module



Features



1. Unique structural design, primary welding molding, avoid secondary sintering

2. Vacuum sintered structure with porosity less than 3%

3. GPP central gate chip ensures high reliability of products

4. High Thermal conductivity DBC Insulation layer

5. Chip welding without flux contamination

6. Small volume light weight



Primary Welding Molding Thyristor Diode Module Big Power Inverse Parallel



Type

IT (AV)

TC=85°C(A)

VDRM

VRRM(V)

IDRM

IRRM(mA)

VTM

(V)

@ITM

(A)

IGT

(mA)

VGT

(V)

di/dt

(A/us)

dv/dt

(V/us)

ITSM

(kA)

I2t

(kA2S)

Rjc

(°C/W)

 Viso(V) Outline
MT*25 25 600-1800 8 1.60 75 100 1.80 50 800 0.55 1.50 0.95 2500 M1 M2 M3
MT*40 40 600-1800 8 1.60 120 100 1.80 50 800 0.70 2.50 0.95 2500
MT*55 55 600-1800 8 1.60 150 100 1.80 50 800 1.00 5.00 0.65 2500
MT*70 70 600-1800 8 1.60 210 100 1.80 50 800 1.25 7.20 0.53 2500
MT*90 90 600-1800 10 1.60 270 100 1.80 100 800 1.60 12.8 0.41 2500
MT*90 90 1900-2400 15 1.60 270 100 1.80 100 800 1.60 12.8 0.41 3000
MT*110 110 600-1800 15 1.60 330 100 2.00 100 800 2.10 24.0 0.28 2500
MT*110 110 1900-2400 15 2.00 330 100 2.00 100 800 2.10 24.0 0.25 3000
MT*135 135 600-1800 20 1.60 410 120 2.00 100 800 3.70 72.2 0.20 2500 M5 M6 M7 M8 M9
MT*135 135 1900-3000 20 2.00 410 120 2.00 100 800 3.70 72.2 0.20 3600 M9
MT*160 160 600-1800 25 1.55 480 120 2.00 100 1000 5.20 145 0.17 2500 M5 M6 M7 M8 M9
MT*160 160 1900-3000 25 2.00 480 120 2.00 100 1000 5.20 145 0.17 3600 M9
MT*182 182 600-1800 25 1.55 550 120 2.00 100 1000 5.80 210 0.15 2500 M5 M6 M7 M8 M9
MT*182 182 1900-3000 25 2.00 550 120 2.00 100 1000 5.80 210 0.15 3600 M9
MT*200 200 600-1800 30 1.55 600 150 2.50 100 1000 6.50 259 0.14 2500 M10 MS10 M11
MT*200 200 1900-2600 35 1.80 600 150 2.50 100 1000 6.50 259 0.14 3200
MT*200 200 2800-3600 40 2.30 600 150 2.50 100 1000 7.10 259 0.14 4500



Shipment and Packaging



Primary Welding Molding Thyristor Diode Module Big Power Inverse Parallel
